General
Depth:  3.7 in
Height:  9.7 in
Weight:  5.5 lbs
Width:  12.2 in
Device Type:  DLP projector
Built-in Devices:  Speaker
Power
Power Device:  Power adapter
Voltage Required:  AC 120/230 V ( 50/60 Hz )
Power Consumption Operational:  278 Watt
Miscellaneous
Cables Included:  1 x VGA cable
Included Accessories:  Lens cover
Compliant Standards:  FCC Class B certified, cUL, NOM, UL 1950, CSA 22.2 No. 950
Expansion / Connectivity
Interfaces:  2 x VGA / component video input - 15 pin HD D-Sub (HD-15) ¦ 1 x HDMI input - 19 pin HDMI Type A ¦ 1 x composite video input - RCA ¦ 2 x audio line-in - mini-phone 3.5 mm ¦ 1 x VGA output - 15 pin HD D-Sub (HD-15) ¦ 1 x audio line-out - mini-phone 3.5 mm ¦ 1 x remote control - 9 pin D-Sub (DB-9) ¦ 1 x remote control - RJ-45 ¦ 1 x S-video input - 4 pin mini-DIN ¦ 1 x audio line-out - RCA phono x 2
Input Device
Type:  Remote control - wireless
Environmental Parameters
Min Operating Temperature:  41 °F
Max Operating Temperature:  104 °F
Humidity Range Operating:  20 - 80% (non-condensing)
Sound Emission:  34 dB
Manufacturer Warranty
Service & Support:  2 years warranty
Service & Support Details:  Limited warranty - parts and labor - 2 years ¦ Limited warranty - lamp - 1 year / 500 hours
Projector / Panel
Image Brightness:  2600 ANSI lumens
Image Contrast Ratio:  2000:1
Image Size:  33.1 in - 299 in
Projection Distance:  4 ft - 39 ft
Resolution:  XGA - XGA (1024 x 768) (native) / 1600 x 1200 (resized)
Native Aspect Ratio:  4:3
Max Sync Rate (V x H):  120 Hz x 100 kHz
Lamp Type:  180 Watt
Lamp Life Cycle:  3500 hour(s) / 5000 hour(s) (economic mode)
Projector Lens System
Focus Type:  Manual
Zoom Type:  Manual
Zoom Factor:  1.1x
Keystone Correction Direction:  Vertical
Vertical Keystone Correction:  -40 / +40
Lens Aperture:  F/2.41-2.55
Video Input
Analog Video Format:  SECAM, PAL, PAL-N, PAL-M, NTSC 4.43, PAL 60
Analog Video Signal:  RGB, S-Video, composite video
Digital Video Standard:  High-Definition Multimedia Interface (HDMI)
Audio Output
Type:  Speaker(s) - internal
Sound Output Mode:  Mono
Output Power / Channel:  7 Watt
Speaker(s):  1 x mixed channel
